Super Flex 1250 Discharge Hose (SF)

Discharge hose with woven fiber reinforcement and an extruded rubber tube. Manufacturer, size,

Description

  • PRODUCT Features
Discharge hose with woven fiber reinforcement and an extruded rubber tube. Manufacturer, size, weight and working pressure embossed on outer wrapper.
  • Factory Part Numbers

    Part NumberSize
    in/mm.    		Mfg. Min. Burst
    (bar/psi)    		Working Pressure
    bar / psi    		Shipping Weight
    lbs. / kg.    		F.W.C.
    (lbs/kg) ft.
    H12SF__C 1-1/4 / 32 170 / 2500 85 / 1233 .71 / .32 1.9 / .9
    H15SF__C 1-1/2 / 38 170 / 2500 85 / 1233 .97 / .44 2.8 / 1.7
    H20SF__C 2 / 51 170 / 2500 85 / 1233 1.5 / .66 4.7 / 2.1
    H22SF__C 2-1/4 / 57.4 170 / 2500 85 / 1233 1.3 / .61 5.5 / 2.5
    H25SF__C 2-1/2 / 63.5 170 / 2500 85 / 1233 1.8 / .82 6.9 / 3.1
    H30SF__C 3 / 76 170 / 2500 85 / 1233 2.5 / 1.1 9.9 / 4.5
    H35SF__C 3-1/2 / 89 170 / 2500 85 / 1233 2.9 / 1.3 12.9 / 5.9
    H40SF__C 4 / 102 170 / 2500 85 / 1233 3.2 / 1.5 16.3 / 7.4
    H45SF__C 4-1/2 / 114 170 / 2500 85 / 1233 3.8 / 1.7 20.3 / 9.2
    H50SF__V 5 / 127 170 / 2500 85 / 1233 4.8 / 1.7 24.2 / 10.9
