N2 Boom Hose (Trelleborg)
Boom hose with four layers of woven wire reinforcement and an extruded rubber tube,
Description
Boom hose with four layers of woven wire reinforcement and an extruded rubber tube, available in 3 to 6 inch diameters.
- PRODUCT Features
Boom hose with four layers of woven wire reinforcement and an extruded rubber tube, available in 3 to 6 inch diameters.
- Factory Part Numbers
| Part Number | Size in/mm. | Mfg. Min. Burst (bar/psi) | Working Pressure bar / psi | Shipping Weight lbs. / kg. | F.W.C. (lbs/kg) ft. |
|---|---|---|---|---|---|
| H30N2__K | 3 / 76 | 200 / 2940 | 85 / 1233 | 3.7 / 1.7 | 11.1 / 5.0 |
| H35N2__K | 3-1/2 / 89 | 200 / 2940 | 85 / 1233 | 4.8 / 2.2 | 15.1 / 6.8 |
| H40N2__K | 4 / 102 | 200 / 2940 | 85 / 1233 | 5.4 / 2.4 | 18.5 / 8.4 |
| H45N2__K | 4-1/2 / 114 | 200 / 2940 | 85 / 1233 | 6.1 / 2.8 | 22.9 / 10.4 |
| H50N2__K | 5 / 125 | 200 / 2940 | 85 / 1233 | 7.6 / 3.4 | 27.4 / 12.4 |
| H60N2__K | 6 / 152 | 200 / 2940 | 85 / 1233 | 9.9 / 4.5 | 38.5 / 17.5 |
