Steel Bond 1250 Boom Hose (SB)

Boom hose with four layers of woven wire reinforcement and an extruded rubber tube. Manufacture size, weight and working pressure are embossed on the outer wrapper.

Description

Boom hose with four layers of woven wire reinforcement and an extruded rubber tube. Manufacture size, weight and working pressure are embossed on the outer wrapper.

  • PRODUCT Features
Boom hose with four layers of woven wire reinforcement and an extruded rubber tube. Manufacture size, weight and working pressure are embossed on the outer wrapper.
  • Factory Part Numbers

    Part NumberSize
    in/mm.    		Mfg. Min. Burst
    (bar/psi)    		Working Pressure
    bar / psi    		Shipping Weight
    lbs. / kg.    		F.W.C.
    (lbs/kg) ft.
    H15SB__C 1-1/2 / 38 170 / 2500 85 / 1233 1.22 / .56 3.1 / 1.4
    H20SB__C 2 / 51 170 / 2500 85 / 1233 1.54 / .70 4.8 / 2.2
    H25SB__C 2-1/2 / 63.5 170 / 2500 85 / 1233 2.24 / 1.0 7.4 / 3.3
    H30SB__C 3 / 76 170 / 2500 85 / 1233 4.29 / 1.9 11.7 / 5.3
    H40SB__C 4 / 102 170 / 2500 85 / 1233 5.30 / 18.4 18.4 / 8.3
    H50SB__C 5 / 127 170 / 2500 85 / 1233 6.51 / 2.9 26.9 / 12.3
